Right Angle Drills

Dotco’s Pistol Grip Drills are ideal choices for any restricted access application. Manufactured with the operator in mind, the drills are small, lightweight and comfortable to use. This optimal combination of tool characteristics allows the operator to focus doing the best job possible as fast as possible.

4 hp / 0.30 kW: 15LF Series
9 hp / 0.67 kW: 15LN Series
Ideal for restricted access applications
Rear exhaust
Lock off safety lever standard

Description

15LF And 15LN Series – Right Angle Drill – Light Duty / Small Head Height
Item	Termination	Free Speed (rpm)	Weight (kg)	Length (mm)
15LF286-62	1/4”-28 I	750	0,8	299,7
15LF285-62	1/4”-28 I	1 000	0,8	299,7
15LF284-62	1/4”-28 I	2 400	0,8	281,9
15LF283-62	1/4”-28 I	3 300	0,7	271,8
15LF282-62	1/4”-28 I	4 000	0,7	271,8
15LF281-62	1/4”-28 I	5 300	0,7	271,8
15LN285-62	1/4”-28 I	1 000	1,1	304,8
15LN282-62	1/4”-28 I	3 100	1,1	304,8
15LN281-62	1/4”-28 I	5 000	1,1	304,8
15LN288-62	1/4”-28 I	5 600	1,1	304,8

15LF And 15LN Series – Right Angle Drill – Heavy Duty Head
Item	Termination	Free Speed (rpm)	Weight (kg)	Length (mm)
15LF287-52	1/4”-28 I	420	0,8	304,8
15LF285-52	1/4”-28 I	700	0,8	304,8
15LF283-52	1/4”-28 I	2 300	0,9	279,4
15LF282-52	1/4”-28 I	2 800	0,9	279,4
15LF281-52	1/4”-28 I	3 700	0,9	279,4
15LN286-52	1/4”-28 I	540	1,4	325,1
15LN285-52	1/4”-28 I	870	1,4	325,1
15LN284-52	1/4”-28 I	1 070	1,4	325,1
15LN283-52	1/4”-28 I	1 300	1,2	292,1
15LN281-52	1/4”-28 I	3 500	1,2	292,1
15LN288-52	1/4”-28 I	3 900	1,2	292,1

Brand

Dotco

Dotco

Dotco's advanced pneumatic grinders and drills are designed to withstand even the most challenging environments. Precisely machined, balanced parts of material removal tools minimize vibration and thus guarantee productivity and ergonomics. As a registered trademark of Apex Tool Group, Dotco tools are about to integrate with the Cleco brand in the near future. Visit manufacturer's website >>
