Inline Grinders

Dotco’s pneumatic inline grinders have become the industry standard for quality and versatility. Trim, ergonomic design enables excellent control and makes even the smallest and lightest tools to withstand in harsh environments. Due to their compact size, inline grinders are particularly well suited for working in tight spaces.

Standard equipped with 200 or 300 series collet
12 000–34 000 rpm
0.3 hp (0.22 kW)
Durable and ergonomic composite (12–10 Series) or aluminium (10–10 Series) housing
Ideal for die and mold work as well as deburring
Comprehensive selection of speed available
Standard equipped with lock-off lever

Description

12-10 Series Inline Grinders
Item	Collet Size	Exhaust	Free Speed (rpm)	Abrasive Capacity	Weight (kg)	Length (mm)	Air Inlet Size
12L1045-36M6*	1/4” & 6 mm	Front	12 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1046-36	1/4”	Front	18 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1028-36	1/4″	Rear	20 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1028-36M6*	1/4” & 6 mm	Rear	20 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1003-36	1/4”	Front	25 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1003-36LH	1/4″	Front	25 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4″
12L1082-36	1/4”	Rear	25 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1082-36M6*	1/4” & 6 mm	Rear	25 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1000-36	1/4”	Front	30 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1000-36LH	1/4″	Front	25 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4″
12L1000-36M6*	1/4” & 6 mm	Front	30 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1080-36M6*	1/4” & 6 mm	Rear	30 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1080-36M6OH*	1/4” & 6 mm	Rear	30 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1001-36 (M6)	1/4”	Front	34 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1081-36	1/4”	Rear	34 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12L1081-36M6OH*	1/4” & 6 mm	Rear	34 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”
12S1008-36	1/4”	Front	20 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4”

10-10 Series Inline Grinders
Item	Collet Size	Exhaust	Free Speed (rpm)	Abrasive Capacity	Weight (kg)	Length (mm)	Air Inlet Size
10L1003-36	1/4”	Front	25 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,3	116,8	1/4”
10L1082-36	1/4”	Rear	25 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,3	116,8	1/4”
10L1000-36	1/4”	Front	30 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,3	116,8	1/4”
10L1000-36LH	1/4″	Front	30 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,4	152,4	1/4″
10L1080-36	1/4”	Rear	30 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,3	116,8	1/4”
10L1001-36	1/4”	Front	34 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,3	116,8	1/4”
10L1081-36	1/4”	Rear	34 000	1/2″ Carbide Burr, 1″ Mounted Wheel	0,3	116,8	1/4”

*) 1/4” and 6 mm collets included.

Brand

Dotco

Dotco

Dotco's advanced pneumatic grinders and drills are designed to withstand even the most challenging environments. Precisely machined, balanced parts of material removal tools minimize vibration and thus guarantee productivity and ergonomics. As a registered trademark of Apex Tool Group, Dotco tools are about to integrate with the Cleco brand in the near future. Visit manufacturer's website >>

Product Sheet

Product Sheet (in Finnish) [PDF]
